BOSCH Series alternator rectifier

Diodes: 6-25A Ampere

Diameter OD: 114mm

With Trio

With "B+" Terminal

With "D+" Terminal

With "W" Terminal

References:

Bosch: 1127011116, 1127320506

Cargo: 131559

Mobiletron: RB-03HA

Transpo: IBR302

Fit Unit: CA345IR

YUNYI: 12421200/BHP11411

For use on: Audi, VW Diesel

Diodes: 6-35A Ampere

Diameter OD: 114mm

With M8*54mm Battery Post

With M5*50mm "D+" Post

With Trio

With "B+" Terminal

References:

Bosch: 1127320601, 1127320661

Cargo: 132668, 230361

Mobiletron: RB-05H

Transpo: IBR316

YUNYI: 242-160/BHP11414

Diodes:6-35A Ampere

Diameter OD:114mm

With M6*47mm Battery Post

Without Trio

With "B+" Terminal

With "W" Terminal

References:

Bosch:9120067027,9121067385

Cargo:136591

Mobiletron:RB-83H

Transpo:IBR388

Yunyi:242-271/BHP11426A

Diodes:3-70A Avalanche

With M8×35.5mm Battery Post

Connection type to the stator delta(Δ)

Diodes:3-50A Avalanche

With M8×30mm Battery Post

Connection type to the stator delta(Δ)

Diodes:3-60A Avalanche

With M8×40mm Battery Post    FIT UNIT:F000BL07G5

Diodes:4-50A Avalanche
With M8+8×33mm Battery Post

FIT UNIT:0272220890

Diodes:14-50A Ampere

Diameter OD:145mm

With M8×52mm Battery Post

With M8×52mm Ground Post

With M5×34.5mm Trio Post

With M5×25mm “W” Post"

"BOSCH:1127320547,1127320571

CARGO:136581

TRANSPO:IBR547

YUNYI:242-AM0/BHO14502"

Diodes:6-80A Avalanche

Diameter OD:140mm

With M8×22.5mm Battery Post

For 28V Alternators

Diodes:10-60A Avalanche

Diameter OD:128mm

With M8×32mm Battery Post

FIT UNIT:0125813002

YUNYI:244-DS0

Diodes:6-60A Avalanche

With M8×23.5mm Battery Post

BOSCH:F00M573907

YUNYI:1244CM00

Diodes:6-70A Avalanche

Diameter OD:128mm

With M8×23.5mm Battery Post

BOSCH:F00M346135

YUNYI:12442800/BHP12815A
